IGPS-9084GP-LA-PN

IGPS-9084GP-LA-PN is layer2 PROFINET Conformance-Class B PoE switch with 8x 10/100/1000Base-T(X) P.S.E. ports and 4x 100/1000Base-X SFP ports. The switch support Ethernet redundancy protocol, O-Ring and MSTP (RSTP/STP compatible) can protect your mission-critical applications from network interruptions or temporary malfunctions with its fast recovery technology. IGPS-9084GP-LA-PN also support Power over Ethernet, total PoE power budget is 240W max, along with data, to remote devices over standard twisted-pair cable in an Ethernet network. IGPS-9084GP-LA-PN support wide operating temperature from -40oC to 75oC. IGPS-9084GP-LA can also be managed centralized and convenient by Open-Vision, Except the Web-based interface, Telnet and console (CLI) configuration.

Features

Support O-Ring (recovery time < 30ms over 250 units of connection) and MSTP (RSTP/STP compatible)

Open-Ring support the other vendor's ring technology in open architecture

O-Chain allow multiple redundant network rings

Support PROFINET MRP client (MRC)

Support PoE on/off schedule, PoE alive check and auto reboot fuction

Support Ethernet/IP and Modbus TCP protocol

Support IEEE 802.3az Energy-Efficient Ethernet technology

Provided HTTPS/SSH protocol to enhance network security

Support IP-based bandwidth management

Support application-based QoS management

Support Device Binding

Support DoS/DDoS auto prevention

IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic

Support SNMP v1/v2c/v3 & RMON & 802.1Q VLAN Network Management

Support ACL, TACACS+ and 802.1x User Authentication for security

Syslog/SNMP Trap notification for warning of unexpected event

Support DBU-01 backup unit device to quickly backup/restore configuration

Web-based ,SNMP v1/v2c/v3, Telnet, Console (CLI), and Windows utility (Open-Vision) configuration

Support LLDP Protocol

Robust EMS design, provide 8K ESD and 4KV Surge protection

DIN-Rail and wall mounting enabled

PROFINET CC-B v2.40 certified and GSD file provided
